Modular hygienic resistance thermometer(TM411-AA2AD1E4CB1C1X30A0A014A1C1A11AA1A1A1+K5Z1),endress+hauser

$502.20
$642.00
-$139.80
Quantity
Sku : TM411-AA2AD1E4CB1C1X30A0A014A1C1A11AA1A1A1+K5Z1
Weight : 6.5kg

Description

  • Estimated Lead Time : 4-6 Weeks

  • Manufacturer : Endress+Hauser

  • Product No. : TM411-AA2AD1E4CB1C1X30A0A014A1C1A11AA1A1A1+K5Z1

TM411-AA2AD1E4CB1C1X30A0A014A1C1A11AA1A1A1

  • Approval = AA : Non-hazardous area

  • Thermowell = 2 :  Detachable process connection

  • Material Wetted Parts = A : 316L

  • Process Connection Type = D1 : Dairy fitting DIN11851

  • Process Connection Size = E4 :  DN50 DIN11851, 3-A, EHEDG, ASME BPE

  • Thermowell External Diameter = C : 9 mm

  • Tip Shape; External Diam = B1:  D2; Length Re: Straight (D1 = D2)

  • Surface Wetted Parts  = C1 :Ra <= 0.76 (D1=9 mm)

  • Immersion Length U = X30 :  135 mm ..... mm (9/12.7mm TW)

  • Neck = A0 : Not needed

  • Neck Length = A0 : E: Not needed

  • Lagging Length = 14 : T: 85 mm

  • Sensor Type = A1 :  Measuring Range: 1xPt100 TF; -50...400oC

  • Insert Design; = C1 : Diam. d; Sheath Material: 3-wire MI-cable; 6mm; 316L

  • Accuracy acc. IEC60751 = A1 : Class A (TF, 6mm)

  • Electrical Connection = 1A  : Terminal block

  • Terminal Head,Material,Protection Class = A1 : TA30A, Alu, IP66/68, NEMA Type 4X

  • Neck Connection Terminal Head = A1 : M24x1.5 female thread

  • Cable Entry Terminal Head = A1 :  1x M20x1.5 female thread

  • Test, Certificate, Declaration = K5 : Final inspection report

  • Z1 >>Marking: Tagging (TAG), metal

K5Z1

  • Measuring principle : Raman spectroscopy

  • Sampling probe compatibility : Raman Rxn-10 probe

  • Temperature range:

  • -30 to 120 °C / -22 to 248 °F (316L stainless steel)

  • -30 to 280 °C / -22 to 536 °F (C276 alloy)

  • -30 to 300 °C / -22 to 572 °F (Grade 2 Titanium)

  • Shipping Weight : 7.5 Kg
