Absolute and gauge pressure Cerabar (Stop Production. New Replacement : PMC11-AA1L1QBWWJJ+F3 Gauge Pressure Cerabar PMC11)(PMC131-A55E2A1T),endress+hauser

$439.20
$561.00
-$121.80
Quantity

Description

  • PMC131-A55E2A1T

  • Cerabar T PMC131 Pressure Transducer With ceramic and metal sensors For absolute pressure and gauge pressure

  • Measurement up to 400 bar

  • Extremely stable, overload-resistant and reliable.

  • Cerabar T is a pressure transducer for measuring absolute pressure and gauge pressure in gases, vapors, liquids and dusts.

  • Hygienic and threaded connections are available as process connections.

  • This compact pressure transducer impresses with its well-engineered construction:

    • High reproducibility and long-term stability.

    • Finely graduated measuring ranges from vacuum up to 400 bar/6000 psi.

    • Ceraphire® ceramic sensor: corrosion-proof, abrasionproof and extremely overload-resistant.

    • Deployed for pressure monitoring up to SIL 2 as per IEC 61508/IEC 61511-1

  • Sensors

    • Dry capacitance ceramic sensor (Ceraphire®) for measuring ranges up to 40 bar

    • overload-resistant,vacuum-proof, stable against alternating load

    • Piezoresistive sensor with metal diaphragm for measuring ranges up to 400 bar

  • Shipping Weight: 1 kg
