3051TG1A2B21BS1/1199WNA95SSCW30LA002(3051TG1A2B21BS11199WNA95SSCW30LA002),rosemount

$1,239.30
$1,584.00
-$344.70
Quantity
Sku : 3051TG1A2B21BS11199WNA95SSCW30LA002
Weight : 1.4kg

Description

  • Estimated Lead Time : 2 - 3 Weeks
  • Manufacturer: Rosemount Inc.
  • Part number:3051TG1A2B21BS1/1199WNA95SSCW30LA002
  • Model: 3051T,In-line pressure transmitter
  • Pressure type: G, Gage
  • Pressure range: 1,–14.7 to 30 psi (–1,01 to 2,06 bar)
  • Transmitter output:A, 4–20 mA with Digital Signal Based on HART Protocol
  • Process connection style:2B, 1/2–14 NPT female (range 1–5 only)
  • Isolating diaphragm: 2,316L SST
  • Process connection wetted parts material:2, 316L SST
  • Sensor fill fluid: 1,Silicone
  • Housing material:B, Aluminium, conduity entry size, 1/2–14 NPT
  • Diaphragm seal assemblies: S1, Assemble to one Rosemount 1199 seal
  • Model: 1199, Seal system
  • Connection type: W, all welded, one seal system
  • Seal fill fluid: N, Neobee M-20,specific gravity,0.94
  • Temperature limit: no extension, 5 to 401 °F
  • (–15 to 205 °C), 2in,(50mm) extension,5 to 437 °F
  • (–15 to 225 °C), 4in,(100mm) extension,5 to 437 °F(–15 to 225 °C), thermal optimizer,5 to 437 °F
  • (–15 to 225 °C)
  • Seal connection type: A, direct mounted
  • Direct mount connection type: 95, In-line one-seal system,
  • Extension length:direct mount, no extension
  • Connection type: All welded
  • Weight: 1.4 kg
  • Shipping weight: 2.0kg
