3051 Pressure Transmitter(3051TG4A2B21AB4KDM5T1Q4),rosemount

$664.20
$849.00
-$184.80
Quantity

Description

  • Estimated Lead time : 4-6 Weeks

  • Manufacturer : Rosemount

  • Product Number: 3051TG4A2B21AB4KDM5T1Q4

  • 3051T - Model : In-Line Pressure Transmitter

  • G - Pressure type : Gage

  • 4 - Pressure range:

    • Gage (Rosemount 3051TG)(1): –14.7 to 800 psi (-1.01 to 55.15 bar)

    • Absolute (Rosemount 3051TA): 0 to 800 psia (0 to 55.15 bar)

  • A - Transmitter output : 4–20 mA with digital signal based on HART® Protocol

  • 2B - Process connection style : ½-14 NPT female (range 0-5 only)

  • 2 - Details Isolating diaphragm

    • Isolating diaphragm: 316L stainless steel

    • Process connection wetted parts material: 316L stainless steel

  • B4 - Mounting bracket: Bracket for 2-in. pipe or panel mounting, all stainless steel

  • KD - USA, Canada, and ATEX Explosion-proof, Intrinsically Safe (combination of K5, C6, I1, and E8)

  • M5 - Display and interface options : LCD display

  • T1 - Transient protection: Transient protection terminal block

  • Q4 - Certification : Calibration certificate

  • Shipping Weight: 4.0 Kg
